Features

  • Hydraulic lifting system
  • Clear digital speed readout
  • Space-saving design
  • Wide variation in power and speed frequency
  • Clamping system by ratchet belt
  • Available in ATEX version
  • Direct drive system

M-series

Capable. Energetic. Substantial.

The Dispermill M-series upscales you laboratory projects to production scale. This universally applicable machine is suitable for batches from 75 to 1000 litres and comes with high-end technology to increase the ease of use.

The Dispermill M-series has been developed according to the latest technical requirements. This dissolver has a hydraulic cylinder for easy up and down movement of the entire mixing unit. The stainless steel mixing shaft is equipped with double bearings. The ergonomically designed control panel gives you control over the machine and has a display where you can easily read the speed. The powerful drive in combination with the ABB microprocessor-controlled motor ensures highly reliable functionality. In addition, this machine has a very compact design, making it easy to fit into your factory.

Product applications

Paints, floor coatings, ceramics, colourants, automotive coatings, inks, sealants, PVC liquids, aerospace coatings, industrial coatings, resin, putties, decorative coatings, textile, additives, wood coatings, plasters, stucco/wall and adhesives.

1
2
3
1

Hydraulic lifting system

2

Clear digital speed readout

3

Clamping system by ratchet belt

Models

M400 M550 M750 M1100 M1500
Power4.0 kW / 5.5 HP5.5 kW / 7.5 HP7.5 kW / 10 HP11,0 kW / 15 HP15,0 kW / 20 HP
Supply400V +/- 10% 50/60 Hz400V +/- 10% 50/60 Hz400V +/- 10% 50/60 Hz400V +/- 10% 50/60 Hz400V +/- 10% 50/60 Hz
Speed200-1800 RPM200-1800 RPM200-1800 RPM200-1800 RPM200-1800 RPM
MX400 MX550 MX750
Power4.0 kW / 5.5 HP5.5 kW / 7.5 HP7.5 kW / 10 HP
Supply400V +/- 10% 50/60 Hz400V +/- 10% 50/60 Hz400V +/- 10% 50/60 Hz
Speed200-1800 RPM200-1800 RPM200-1800 RPM
